Product Description
200w LED Dimmable Driver 12v or 24v DC
- Compatible with our Range of Dimmable Controllers
- Maximum Load of 200w/ 12v or 24v DC Driver
Our new dimmable driver is perfect for use with our dimmable LED products, such as the recommended Varilight Pro Dimmer.
For optimum usage, we recommend that you use a minimum 10% load, any less than this may induce flickering.
Suitable for leading/trailing edge.
We have a large range of drivers/transformers to suit whatever minimum/maximum load you require. Please don't hesitate to contact our team if you need any advice.
Features:
- Built-in active PFC function (PF>0.95)
- Cooling by free air convection
- IP66 Design
- Fully isolated, delivering up to 200W of power
- Short circuit/ Over voltage protection
Specifications
-
SKU ELED-200-12T
-
Width 77.5mm The width of the product. Normally measured in mm unless otherwise stated.
-
Voltage 12V The operating voltage of the product. 220-240v AC is UK mains voltage (What comes out of your plug sockets). So if the voltage shown is below 220v then you will more than likely need a transformer for the light to operate.
-
Length 226.5mm The physical length of the product
-
Height 47mm The overall height of the product at the tallest point.
-
Delivery Time Available Next Day if Ordered Before 3pm
-
Finish Grey The overall visible finish of the product. Such as stainless steel, chrome, white etc.
-
Dimmable Yes Whether the brightness is dimmable or not. Some products are dimmable via specialist remote control systems we supply. Whereas some products are dimmable with mains voltage wall dimmer.
-
IP66 Ingress protection rating. Classifies the degree of protection against water and dust.
-
Lamp Base Integrated LED Indicates the size of the electrical connection at the bottom of the light source. Such as screw or bayonet etc. If you are confused with what you require please feel free to contact us for us.
-
Maximum Load 200 The maximum electrical load that the product is manufactured to accept. Normally measured in Watts or AMP. EG, if you have a product which is 150w and lights which are 50w each then 3 x 50w = 150w which is the maximum load.
-
Wattage 200 The total electrical power used of the light. A higher wattage no longer guarantee’s that the light is brighter. EG: there are LED products which are 5w which is equal in brightness to a 50w incandescent bulb.
