Leading & Trailing Edge LED Dimming
This dimmer module supports both leading edge and trailing edge dimming technologies. This means that you’re not limited to a single dimming method, allowing you to utilise this module with a wide range of dimmable fittings.
This module’s default is set to trailing edge, which is a dimming method commonly used for dimmable LED lighting. This should help your LED lights avoid flickering when adjusting their brightness. Choose this dimming method if you’re using LED lights for your setup.
The leading edge, on the other hand, offers an alternative to traditional lighting controls, including incandescent bulbs, halogen lamps, and magnetic low-voltage (MLV) transformers. Using this on LEDs can cause buzzing or flickering, so make sure the module is set to the correct dimming method.
This module is particularly useful for mixed-lighting projects that use different lamps.
Compact Module for Space-Saving Installations
Thanks to its slim dimensions of just 56.8mm x 25mm x 43.2mm, this dimmer module fits in virtually any compact installation, giving you advanced lighting control without sticking out or taking up valuable space. The slim body also means you can easily fit it behind a compatible switch plate or in other confined wiring spaces.
This compact build truly shines in retrofit projects or when upgrading an existing lighting setup, as the space behind the switch is often limited by the back box, wiring, and surrounding components.
New lighting installations also benefit from the neat, unobtrusive control setup, so a space-saving component like this dimming module is always a favourite. This is especially ideal for modern minimalist interiors and interiors that focus on clean designs.
Supports Two-Way Dimming Control
The module supports two-way switching. This means that the brightness of the same connected lights can be adjusted from two different switch locations. This is especially useful in hallways and staircases, where you or other people using the space may need to control the same lights from either end.
Another practical installation is in the bedroom, where the switches can be fixed in convenient locations such as the bedside area. The same is true for larger living areas where relying on a single control point would be less practical.
This feature allows you to create a more practical and intuitive lighting layout that suits the way people move through and use a room, rather than forcing you to adjust to inconvenient switch positions, as is typical in many UK homes.
Suitable for LED and Incandescent Lighting
Given that the dimmer module comes built-in with two different dimming technologies, you can use it for both dimmable LED lamps and traditional incandescent bulbs. This high compatibility is particularly useful for retrofit projects or when upgrading an existing installation. It can support modern LED lighting, but it can also accommodate older incandescent sources where they remain in use.
Bear in mind that the connected lighting load must fall between a 5W minimum and a 150W maximum, so proper measurement (of the setup’s total wattage) and planning are needed before final installation.
Staying within the intended range helps the dimmer operate as designed and avoids problems such as circuit overload and reduced maximum brightness. The high maximum capacity means the module can support multiple suitable LED lamps on a single circuit, provided their combined wattage remains within the stated limit.
Durable Construction with Long-Term Reliability
The durable enclosure housing the dimmer module's internal components is made of robust polycarbonate. This material is well-suited to electrical accessories because it combines strength with lightweight construction, protecting them from knocks or damage that could affect the module's performance. This makes the module a reliable choice for lighting circuits that are regularly switched on, turned off, and dimmed in homes and commercial spaces.
The product also comes with a 3-year warranty, giving you added confidence in its quality and long-term performance. If you are upgrading an existing lighting setup or planning a new installation, the combination of a durable housing and a warranty means you can install the module with confidence, knowing it is designed for continued use. This can give you greater peace of mind knowing you will not have to worry about replacing the dimmer soon after installation.
Designed for Safe and Professional Installation
This dimmer module is mains-powered and operates from a 220-240V AC supply, so it can be connected directly to your mains circuit. Its terminals support cable sizes from 0.5mm² to 1.5mm². Using incompatible sizes might compromise an otherwise secure connection, so make sure this is followed. Connecting to the mains power should be done by qualified, licensed electricians for safety and to ensure the installation complies with current UK wiring requirements.
The module also complies with BS EN 60669-2-1, the applicable standard stated for this electronic switching and control product. For a reliable performance, ensure that proper wiring is observed. Check whether the terminal connections are secure and that the circuit load is within the limits.
